Frame -Crafty Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
Rear shock -Fox Float-X LV Performance, 185x55mm. Settings: compression 2 positions lever, low-speedrebound, air preload. Trunnion top mount, 30x8mm bottom bushingsShock settings -CS40 compression, RL60 rebound, Rezi B40, LML, 0.2 volume spacer
Fork -Fox 38 29 Float GRIP Performance, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mmaxle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, airpreload
Headset -Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
Stem -Onoff S6 30mm 0°, 6061 forged alloy + CNC, 31.8mm barbore
Handlebar -Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8° backsweep, 5° upsweep, 31.8mm barbore.L and XL size: 1.5 rise
Grips -Onoff Forest, 1lock-on, 135mm
Seatpost -Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), ML size: 180-155mm (468-275mm), L size: 210-185mm (528-305mm), XL size: 210-185mm (528-305mm)
Saddle -Ergon SM-10
Front brake -Shimano XT M8120, 4 piston caliper, MT800 ICE-Tech 203mm CenterLock rotor, resin pads with fin
Rear brake -Shimano XT M8120, 4 piston caliper, MT800 ICE-Tech 203mm CenterLock rotor, resin pads with fin
Brake lever -Shimano XT M8100, ergonomic antiskid lever with servo wave, tool less reach adjust, free strokeadjust
Rims -Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
Spokes -Mavic J-bend double butted, contactless lacing
Front hub -Mavic, Boost 15x110mm, IS 6 bolts
Rear hub -Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, XD freehub
Front tire -Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Rear tire -Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Crankset -Race Face Aeffect-R ebike, 160mm
Rings -Race Face, 34T, steel, direct mount
Chain -Shimano XT M8100, 12s
Rear derailleur -Shimano XT M8100, SGS, Shadow+
Shift levers -Shimano XT M8100, Rapid Fire Plus, 12s
Cassette -Shimano XT M8100 10-51T Hyperglide+, 12s
Display -Purion 400 / Bosch Mini Remote / Bosch System Controller
Motor -Bosch Performance Line CX (25Km/h) SMART SYSTEM (BDU384Y)
Battery -Bosch Powertube 800Wh
